PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 1 of 13
Magnetic Particle Examination
Procedure
( ASME)
Activity Name Position Date Signature
Approved Adi Padmo ASNT Level III
Cert. No. 126596 January 26, 2012
Reviewed Lili Sianipar President Director January 26, 2012
Prepared Desri ASNT – Level II January 26, 2012
KS
PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 2 of 13
Daftar Isi / Table of Content
Par. Uraian Par. Description Page
Daftar Isi Table of Content 2
1 Tujuan 1 Purpose 3
2 Ruang Lingkup 2 Scope 3
3 Laporan 3 Records 3
4 Referensi 4 References 4
5 Definisi – Definisi 5 Definitions 4
6 Qualifikasi dan Tanggung Jawab 6 Qualification and Responsibility 4
7 Perlengkapan 7 Equipment( s) 4
8 Media Pengujian 8 Examination Medium 5
9 Persyaratan Keselamatan 9 Safety Requirement 5
10 Instruksi – Instruksi 10 Instructions 6
11 Kalibrasi 11 Calibration 6
Persyaratan Yoke AC or DC Yoke AC or DC Requirements. 6
11.1 AC Yoke 11.1 AC Yoke 6
11.2 DC Yoke 11.2 DC Yoke 6
12 Pencahayaan. 12 Illumination. 7
13 Teknik Pemagnetan 13 Magnetizing Technique 7
14 Aplikasi Magnetic Particle 14 Magnetic Particle Applications 8
15 Cakupan Pengujian 15 Examination Coverage 8
16 Penginterprestasian Indikasi 16 Interpretation of Indications 9
17 Pengevaluasian Indikasi 17 Evaluation of Indications 10
18 Acceptance Standard 18 Acceptance Standard 10
19 Repair 19 Repair 12
20 Demagnetisasi 20 Demagnetisation 12
21 Pembersihan akhir 21 Post Cleaning 12
Lampiran Exhibit 13
tabel T - 721 Table T - 721 14
KS
PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 3 of 13
1 Tujuan 1 Purpose
a. Untuk meyediakan petunjuk dan standar
penerimaan pelaksanaan pengujian dengan
magnetic particle pada material
ferromagnetic dengan menggunakan Yoke
metode kontinyu.
a. This procedure provides guidance and
acceptance standards during the conduct of
magnetic particle examination of
ferromagnetic materials using Yoke with
continuous method.
b. Procedure ini terdiri dari versi Enggris dan
Indonesia, jika ada konflik antara keduanya
maka versi Enggris yang dipakai.
b. This procedure consists of English and
Indonesian versions, should there is conflict
between these versions the English version
shall govern.
2 Ruang Lingkup 2 Scope
2.1 Prosedur ini berlaku untuk pelaksanaan MT
yang dilakukan pada permukaan benda
dengan temperature tidak lebih dari 600° F
( 316° C) untuk Partikel Kering dan temperatur
tidak lebih dari 135° F ( 57° C) untuk Partikel
Basah. Untuk keduanya maka instruksi dari
manufaktur pembuat harus diperhatikan.
2.1 This procedure is applicable for MT
performed on surfaces whose temperature
does not exceed 600° F ( 316° C) for Dry
Particle and temperature does not exceed
135° F ( 57° C) for Wet Particle. For both wet
and dry particle examinations, the
instruction of the particle manufacturer shall
be considered.
2.2 Pengujian Lasan dengan Partikel Magnetik
harus termasuk material dasar setidaknya 1”
( 25 mm) tiap sisi lasan bila dimungkinkan.
2.2 Magnetic particle examination of welds
shall include base metal for at least 1” ( 25
mm) on each side of the weld where
possible.
2.3 Qualifikasi Procedure harus dilaksanakan
jika ada perubahan essential variable dari
persyaratan di Table T – 721; jika perubahan
nonessential variable dari persyaratan di
Table T – 721 tidak diperlukan requalifikasi
procedure. Semua perubahan dari essential
atau non essential variable pada nilai, range
nilai, yang disebut dalam prosedur harus
diperlukan revisi pada, atau dengan
addendum untuk prosedur yang tertulis.
2.3 Procedure Qualification shall be made when
a change essential variable of a requirement
in Table T - 721 ; a change nonessential
variable of a requirement in Table T – 721
need not re-qualification of written
procedure. All changes of essential or non
essential variable from the value, or range
value, specified by the written procedure
shall require revision of, or an addendum to,
the written procedure.
3 Laporan 3 Records
Hasil pengujian MT harus dilaporkan pada
format Laporan MT ( Exhibit 1)
Results of MT examination shall be reported
on the MT report form ( Exhibit 1)
4 Referensi 4 References
4.1 PT. KEHAN SUPPLY’ s Written Practice
Procedure No. 01 – QCP - KS
4.1 PT. KEHAN SUPPLY’ s Written Practice
Procedure No. 01 – QCP - KS
4.2 ASME 2010 Code Sect. I, V, VIII Div. 1 ( SNI
13-3498-2002) , VIII Div. 2 ( SNI 13-3498-
2002) , Section IX and ASME B31.1
4.2 ASME 2010 Code Sect. I, V, VIII Div. 1
( SNI 13-3498-2002) , VIII Div. 2 ( SNI 13-
3498-2002) , Section IX and ASME B31.1
KS
PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 4 of 13
5 Definisi – Definisi 5 Definitions
5.1 MT: Pengetesan dengan magnetic particle. 5.1 MT: Magnetic particle Test
5.2 NDE: Test dengan tanpa merusak. 5.2 NDE: Non Destructive Test.
5.3 Metode kontinyu: arus magnet tetap hidup
saat pengaplikasian medium pengujian dan
sampai saatnya penghilangan kelebihan
partikel kering, pada penggunaan dry particle.
5.3 Continuous method: that is, the magnetizing
current remains on while the examination
medium is being applied and while the
excess of the dry particles are being
removed, in use of dry particles.
6 Qualifikasi dan Tanggung Jawab 6 Qualification and Responsibility
6.1 Personel yang melakukan pengujian untuk
memenuhi syarat – syarat dari spesifikasi ini
harus di qualifikasi sesuai dengan prosedur
dari PT PT. KEHAN SUPPLY, no. 01 – QCP
- KS
6.1 Personnel performing examinations to the
requirements of this specification shall be
qualified in accordance with PT PT.
KEHAN SUPPLY’ s written practice, no. 01
– QCP - KS
6.2 Personel yang menentukan keberterimaan
sesuai syarat – syarat dari prosedur ini harus
Level II atau Level III.
6.2 Personnel determining the acceptability to
the requirements of this procedure shall be
Level II or Level III.
7 Perlengkapan 7 Equipment( s)
7.1 Manufaktur dan model dari peralatan MT
Yoke, yang boleh dipakai seperti yang
berikut, tapi tidak terbatas:
7.1 Manufacturer and model of MT Yoke
equipment, which may be used as follows,
but not limited :
Magnaflux, model Y-6. Magnaflux, model Y-6.
Tie de Model TWM 220 N ( AC) Tie de Model TWM 220 N ( AC)
Contour probe, B310DC, Parker Research
( DC)
Contour probe, B310DC, Parker Research
( DC)
7.2 Black light harus bisa menghasilkan intensity
minimum 1000 ¼ W/ cm² pada permukaan
benda yang diuji.
7.2 The black light shall result the intensity a
minimum of 1000 ¼ W/ cm² on the surface
of the part being examined .
7.3 Sebuah piringan metal lapis dua berbentuk
segi delapan, mengandung cacat buatan untuk
verifikasi kekuatan atau arah, atau keduanya
dari medan magnet.
7.3 An octagonal bi-metal disk, containing
artificial flaws used to verify the adequacy
or direction, or both, of the magnetizing
field
8. Media Pengujian 8. Examination Medium
8.1 Partikel kering atau basah, visible atau
fluorescent dye particles harus digunakan
sebagai media pengujian, disesuaikan dengan
kebutuhan.
8.1 Dry or wet particles, visible or fluorescent
dye particles shall be used as the
examination medium, as applicable.
8.2 Merk dan produk lain dari yang disebut di
prosedur ini bisa digunakan asalkan
demonstrasi untuk bisa memuaskan
8.2 Brand name or products other than specified
in this procedure may be used provided
demonstration to the satisfaction of the
KS
PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 5 of 13
Authorized Inspector harus dilaksanakan. Authorized Inspector be performed.
8.3 Pada semua hal recomendasi dari pabrik
pembuat harus dikuti.
8.3 In all cases manufacturer’ s recommendation
shall be followed.
8.4 Partikel kering yang digunakan untuk media
pengujian harus memiliki permiabilitas yang
tinggi dan kemampuan menyimpan magnet
yang rendah dan harus bebas dari karat,
gemuk, cat, kotoran, atau material lain yang
mengganggu fungsi dari alat tersebut. Ukuran,
bentuk, dan warna partikel harus memenuhi
sensitifitas dan kontras yang sesuai untuk
penggunaannya. Magnaflux # 1 ( abu-abu) ,
# 3A ( hitam) or # 8A ( merah) harus
digunakan.
8.4 The dry particles used for the examination
medium shall be of high permeability and
low retentivity and free from deleterious
rust, grease, paint, dirt, or other material,
which might interfere with their proper
functioning. Particles shall be of such size,
shape, and color as to provide adequate
sensitivity and contrast for the intended
use.. Magnaflux # 1 ( gray) , # 3A ( black) or #
8A ( red) shall be used.
8.5 Partikel basah, warnanya harus cukup kontras
dengan permukaan yang diuji. Partikel ini
harus dicampur dalam cairan medium yang
sesuai dengan konsentrasi yang disyaratkan
pabrik pembuat. Magnaflux – 7HF ( MPI Ink)
harus digunakan. Jika diperlukan untuk
menambah contrastnya particle, coating
temporer bisa diaplikasikan pada permukaan
yang tidak di coating, Magnaflux WCP – 2
( MPI white contrast) mungkin digunakan.
8.5 Wet particles, the colour of the particle shall
provide adequate contrast with the surface
being examined. The particle shall be
suspended in a suitable liquid medium in the
concentration recommended by the
manufacturer. Magnaflux – 7HF ( MPI Ink)
shall be used. If necessary to enhance
particle contrast, temporarily coating may be
applied on uncoated surfaces, Magnaflux
WCP – 2 ( MPI white contrast) may be used.
9 Persyaratan Keselamatan 9 Safety Requirement
Peringatan keselamatan dari Pabrik harus
diikuti selama pengujian.
ManufacturerI’ s Safety precautions shall be
followed .
10 Instruksi – Instruksi 10 Instructions
10.1 Persiapan Permukaan 10.1 Surface Preparation
10.2 Sebelum dilaksanakan pengujian, permukaan
yang akan diuji dan area dengan jarak
setidaknya satu inchi setiap sisinya area
tersebut, harus kering, bebas dari semua
kotoran, grease, oli, pasir, loose, rust, scale,
atau material lainnya yang akan mengganggu
pada saat pengujian.
10.2 Prior to magnetic particle examination, the
surface to be examined and any adjacent
area within at least one inch of the surface to
be examined, shall be dry and free of any
dirt, grease, oil, sand, loose, rust, scale, or
any other foreign material which would
interfere with examination.
10.3 Jika menguji lasan, minimum satu inch dari
kedua sisi lasan harus diikutkan kedalam area
yang diamati, jika bisa.
10.3 When examine the welds, at least one inch
both side of the weld shall be included in
area of interest, if practicable.
10.4 Persiapan material dengan menggunakan
gerinda atau mesin disyaratkan apabila
terdapat ketidakteraturan permukaan yang
menutupi indikasi dari kemungkinan cacat.
10.4 Preparation of the materials by grinding or
machining may be required where surface
irregularities would mask indications of
unacceptable discontinuities.
11 Kalibrasi 11 Calibration
KS
PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 6 of 13
Kekuatan angkat magnet dari AC atau DC
Yoke harus harus dibuktikan sekali dalam
setahun.
Kalibrasi lain tidak diperlukan untuk Yoke.
The magnetizing strength of the AC or DC
Yoke shall be determined at least once a
year.
No other calibration is required for the
Yoke.
11.1 AC Yoke 11.1 AC Yoke
AC Yoke harus ditentukan dengan
kemampuan angkat 10 pound ( 4.5 kg) plat
ferromagnetik menggunakan maksimum spasi
dari kaki MT Yoke tersebut yang digunakan
dalam pengujian.
The AC Yoke shall be determined by its
ability to lift a 10 pound ( 4.5 kg) plate of
ferromagnetic material using the leg spacing
( maximum) to be used during MT
examination.
11.2 DC Yoke 11.2 DC Yoke
a DC Yoke harus ditentukan dengan
kemampuan angkat 40 pounds ( 18.2 kg) plat
ferromagnetik menggunakan maksimum spasi
dari kaki MT Yoke tersebut yang digunakan
dalam pengujian.
a The DC Yoke shall be determined by its
ability to lift a 40 pounds ( 18.2 kg) plate of
ferromagnetic material using the leg spacing
( maximum) to be used during MT
examination.
b Kekuatan angkat magnet dari DC Yoke harus
harus diverifikasi setiap saat selama saat
pengujian, dengan kemampuan angkat 40
pound ( 18.2 kg) plat ferromagnetik
b The magnetising strength of the DC Yoke
shall be verified at any time during
examination by its ability to lift a 40 pounds
( 18.2 kg) minimum plate of ferromagnetic
material.
12 Pencahayaan. 12 Illumination.
12.1 Particle Nonfluorescent; pengujian
menggunakan particle nonfluorescent harus
dilaksanakan dengan cahaya visible.
Minimum intensity cahaya 100 fc ( 1000 Lx)
pada permukaan kerja dibutuhkan untuk
meyakinkan sensitivitas selama pengujian dan
evaluasi dari indikasi mencukupi.
12.1 Nonfluorescent Particle; examination using
nonfluorescent Particle shall be performed
under visible light. A minimum light
intensity of 100 fc ( 1000 Lx) at work
surface is required to ensure adequate
sensitivity during the examination and
evaluation of indications.
12.2 Sumber cahaya, teknik yang digunakan, dan
level verifikasi dibutuhkan untuk
didemonstrasikan satu kali, didokumenkan,
dan disimpan sebagai file.
12.2 The light source, technique used, and light
level verification is required to be
demonstrated one time, documented, and
maintained on file.
12.3 Particle Fluorescent; pengujian
menggunakan particle fluorescent harus
dilaksanakan dengan cahaya ultraviolet ( black
light) . Pengujian harus dilaksanakan seperti
dibawah ini :
12.3 Fluorescent Particle; examination using
fluorescent Particle shall be performed
under an ultraviolet light ( black light) . The
examination shall be performed as follows :
a. Pengujian harus dilaksanakan di daerah yang
gelap.
a. It shall be performed in a darkened area.
b. Penguji harus didalam daerah gelap minimum
5 menit sebelum melaksanakan pengujian
untuk bisa beradaptasi dengan pandangan
gelap. Jika penguji memakai kaca mata atau
b. The examiner shall be in a darkened area at
least 5 minutes prior to performing the
examination to enable his eyes to adapt to
dark view. If the examiner wears glasses or
KS
PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 7 of 13
lensa mata , mereka tidak boleh bersifat
photosensitive.
lenses, they shall not be photosensitive.
c. Black light harus diberi untuk pemanasan
minimum 5 menit sebelum digunakan atau
diadakan pengukuran intensity dari sinar
ultraviolet yang dikeluarkan.
c. The black light shall be allowed to warm up
for a minimum of 5 minutes prior to use or
measurement of intensity of ultraviolet light
emitted.
d. Intensitas dari Black light harus diukur
dengan black light meter. Minimum 1000 ¼
W/ cm² pada permukaan dari part yang diuji
dibutuhkan. Black light intensitas harus
diukur minimum sekali dalam 8 jam, dan jika
tempat pengujian berpindah.
d. The black light intensity shall be measured
with a black light meter. A minimum of
1000 ¼ W/ cm² on the surface of the part
being examined shall be required. The black
light intensity shall be measured at least
once every 8 hours, and whenever the work
station is changed.
13 Teknik Pemagnetan 13 Magnetizing Technique
13.1 Kekuatan medan magnet harus diverifikasi
sebelum pengujian dengan menggunakan Pie
– Shaped Magnetic Particle Field Indicator.
Pie – Shaped Magnetic Particle Field Indicator
di posisikan pada permukaan yang diuji,
dimana sisi yang ada tembaganya jauh dari
permukaan yang diinspeksi. Magnetic particle
diaplikasikan berbarengan dengan magnetisasi;
kekuatan magnet cukup ditunjukkan jika bisa
terbentuk garis yang jelas dari kumpulan
magnetic particle memotong permukaan
tembaga dari indikator.
13.1 Field strength shall be verified prior to
examination by using Pie – Shaped
Magnetic Particle Field Indicator.
Pie – Shaped Magnetic Particle Field
Indicator shall be positioned on the surface
to be examined, such that the copper-plate
side is away from the inspected surface. The
magnetic particle are applied simultaneously
with the magnetizing force; the sufficient
field strength is indicated when a clearly
define lines of magnetic particles forms
across the copper face of indicator.
13.2 Observasi indikasi harus dilaksanakan setelah
aliran listrik hidup dan magnetic particles di
aplikasikan.
13.2 Observation of indications shall be
performed upon the magnetizing current on
and magnetic particles being applied.
13.3 Final interpretasi untuk AC Yoke harus
dilaksanakan setelah aliran listrik tetap hidup
minimum selama 5 ( lima) detik.
13.3 Final interpretation for AC Yoke shall be
performed after the magnetizing current
remain on at least 5 ( five) second.
13.4 Final interpretasi untuk DC Yoke harus
dilaksanakan setelah aliran listrik tetap hidup
minimum selama 30 ( tiga puluh) detik .
13.4 Final interpretation for DC Yoke, shall be
performed after the magnetizing current
remain on at least 30 ( thirty) second.
14 Aplikasi Magnetic Particle 14 Magnetic Particle Applications
14.1 Partikel Kering. 14.1 Dry particles.
Tempatkan yoke di area yang akan diuji,
nyalakan arusnya dan semprotkan serbuk
partikel pada permukaan. Bentuk-bentuk dari
indikasi harus terus diamati selama
pengaplikasian partikel magnetis. Kelebihan
partikel yang terbentuk akibat pemakaian
partikel tersebut harus dihilangkan dengan
Place yoke in the area to be examined, turn
on current and light dust the particles with a
powder blower over the surface. Formation
of indications shall be observed during
application of the magnetic particles. Excess
dry particles shall be removed by means of a
dry air current of sufficient force to remove
KS
PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 8 of 13
udara tekanan tertentu untuk menghilangkan
kelebihan partikel tanpa mengganggu indikasi
/ kemungkinan indikasi.
the excess particles without disturbing
indications, which formed during
application of the particles.
14.2 Partikel-partikel basah. 14.2 Wet particles.
Tempatkan yoke pada area yang diuji,
nyalakan arus dan semprotkan partikel basah
secara merata. Bentuk dari indikasi harus
diamati selama aplikasi partikel magnetis.
Place yoke in the area to be examined, turn
on current and uniformly applied wet
particles. Formation of indications shall be
observed during application of the magnetic
particles.
15 Cakupan Pengujian 15 Examination Coverage
15.1 Setidaknya dua pengujian terpisah dilakukan
pada setiap area. Pengujian kedua dengan
fluks magnetic harus dilakukan dengan arah
tegak lurus terhadap hasil dari arah pengujian
yang pertama.
15.1 At least two separate examination shall be
carried out on each area. The second
examination shall be with the magnetic flux
approximately perpendicular to that used in
the first examination.
15.2 Semua pengujian harus dilakukan dengan
overlap yang cukup untuk menjamin cakupan
100% sensitifitas testnya.
15.2 All examination shall be conducted with
sufficient overlap to assure 100% coverage
at established test sensitivity.
15.3 Untuk metode yoke , pengujian secara
menyamping dibatasi, sampai jarak maximum
¼ dari jarak kontaknya pada masing – masing
sisi dari garis terpendek dari jarak kontak
untuk meyakinkan area dibawahnya telah
diuji.
15.3 For the yoke method, lateral examination
area shall be limited, to a maximum distance
of ¼ of the contact spacing on either side of
the shortest line between the contact spacing
to ensure the area under the contact is
examined.
15.4 Untuk inspeksi las, lasan dan sekurangnya
jarak 1” ( 25 mm) dari base metal setiap
sisinya harus diperhatikan sebisa mungkin.
15.4 For welding inspections, the weld and a
least 1” ( 25 mm) of base material on each
side of the weld shall be examined where
possible.
16 Penginterprestasian Indikasi 16 Interpretation of Indications
16.1 Interpretasi dari indikasi dalam pengujian
magnetic particle harus dilaksanakan dengan
pencahayaan yang cukup.
16.1 The interpretation of indications in
Magnetic particle examinations shall be
carried out in the sufficient illuminations
16.2 Kemampuan operator untuk menginterprestasi
pola indikasi dari serbuk terutama pada
permukaan dibawahnya dan pada akar las
pada lasan parsial penetrasi . Pengamatan
terbaik yang bisa dilakukan operator adalah
dengan menggali lebih dalam untuk
menampakkan indikasi. Gambar ditail dari
sambungan parsial penetrasi akan membantu
operator untuk mengevalusi pola dari serbuk.
16.2 Operator skill must be developed in the
interpretation of powder indication patterns
especially in the evaluation of sub-surface
defect vs. unfused roots on partial
penetration welds. This can best be done
through observation by the operator of
excavations made to explore indications.
Drawings that show the details of partial
penetration joints will help the operator
evaluate the particle pattern.
16.3 Area pada toe of fillet welds dapat juga
menyebabkan false indikasi jika terdapat
16.3 The area at the toe of fillet welds can also
cause false indications when an abrupt
KS
PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 9 of 13
perubahan bentuk yang tajam. Uji ulang
setelah penggerindaan dan penghalusan pada
fillet weld menghasilkan transisi yang lebih
halus dari lasan ke base metal akan
menunjukan apakah tersebut false indikasi.
section change is present. Re – examination
after grinding and blending the edge of the
fillet weld to provide a smooth transition
from weld to base metal will determine
whether indication is false.
16.4 Kondisi ini dapat diminimalkan dengan
penyemprotan tipis, merata dengan partikel
magnetik.
16.4 This condition can be minimized by
applying a light, uniform coating of
magnetic particles.
17 Pengevaluasian Indikasi 17 Evaluation of Indications
17.1 Indikasi akan tampak dengan terkumpulnya
partikel magnetik cacat. Kekasaran
permukaan, kotoran, oli dan gemuk akan
menyebabkan indikasi yang false .
17.1 Indications are revealed by retention of
magnetic particles on the discontinuities.
Surface roughness, dirt, oils and grease can
cause false indication.
17.2 Indikasi yang benar disebabkan oleh
ketidaksempurnaan mekanik pada material las
dan area disekitarnya.
17.2 True indications are caused by mechanical
imperfections in the weld material and in the
adjacent area.
17.3 Indikasi yang relevan adalah yang memiliki
dimensi lebih besar dari 1/ 16 in ( 1.5 mm) .
17.3 Relevant indications are those having a
dimension greater than 1/ 16 in ( 1.5 mm) .
17.4 Indikasi memanjang adalah yang memiliki
panjang lebih dari 3 ( tiga) kali lebarnya.
17.4 A linear indication is one having a
length greater than 3 times its width.
17.5 Indikasi bundar adalah indikasi bentuk
melingkar atau ellips dengan panjang sama
atau kurang dari 3 kali lebarnya.
17.5 A rounded indication is one of circular or
elliptical shape with a length equal to or
less than three times its width.
18 Standar Penerimaan 18 Acceptance Standard
18.1 ASME BPV Code Section I, Appendix A,
Para A-260
18.1 ASME BPV Code Section I, Appendix A,
Para A-260
a) Hanya indikasi dengan dimensi terbesar
lebih dari 1.5 mm ( 1/ 16 in.) harus disebut
relevan,
b) Semua permukaan harus bebas dari :
1) indikasi memanjang yang relevant
2) Indikasi bundar yang relevan yang lebih
dari 5 mm ( 3/ 16 in.)
3) Empat atau lebih indikasi bundar yang
relevant pada satu garis yang terpisah
oleh 1/ 16” ( 1.5 mm) atau lebih kecil,
( jarak dari pinggir ke pinggirnya)
a) Only indications with major dimensions
greater than 1.5 mm ( 1/ 16 in.) shall be
considered relevant,
b) All surfaces to be examined shall be free
of:
1) Relevant linear Indications
2) Relevant rounded indications greater
than 5 mm ( 3/ 16 in.)
3) Four or more rounded indications in a
line separated by 1.5 mm ( 1/ 16 in.) or
less, ( edge to edge)
18.2 ASME BPV Code Sect. VIII Div. 1 ,
Appendix 6 , Para 6.3 & 6.4
18.2 ASME BPV Code Sect. VIII Div. 1 ,
Appendix 6 , Para 6.3 & 6.4
A. Hanya indikasi dengan dimensi terbesar
lebih dari 1.5 mm ( 1/ 16 in.) harus disebut
A. Only indications which have any
dimension greater than 1.5 mm ( 1/ 16 ins)
KS
PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 10 of 13
relevan,
B. Semua permukaan harus bebas dari :
1) indikasi memanjang yang relevant
2) Indikasi bundar yang relevan yang lebih
dari 5 mm ( 3/ 16 in.)
3) Empat atau lebih indikasi bundar yang
relevant pada satu garis yang terpisah
oleh 1/ 16” ( 1.5 mm) atau lebih kecil,
( jarak dari pinggir ke pinggirnya)
shall be considered relevant,
B. All surfaces to be examined shall be free
of:
1. Relevant linear Indications
2. Relevant rounded indications greater
than 5.0 mm ( 3/ 16 ins)
3. Four or more relevant rounded
indications in a line separated by 1.5
mm ( 1/ 16 ins) or less, edge to edge
18.3 ASME BPV Code Sect. VIII Div. 2,
Part7.5.6.1 ( d)
18.3 ASME BPV Code Sect. VIII Div. 2,
Part7.5.6.1 ( d)
A. Hanya indikasi dengan dimensi terbesar
lebih dari 1.5 mm ( 1/ 16 in.) harus disebut
relevan,
B. Semua permukaan harus bebas dari :
1) indikasi memanjang yang relevant
2) Indikasi bundar yang relevan yang lebih
dari 5 mm ( 3/ 16 in.)
3) Empat atau lebih indikasi bundar yang
relevant pada satu garis yang terpisah
oleh 1/ 16” ( 1.5 mm) atau lebih kecil,
( jarak dari pinggir ke pinggirnya)
A. Only indications which have any
dimension greater than 1.5 mm ( 1/ 16 ins)
shall be considered relevant
B. All surfaces to be examined shall be free
of:
1. Relevant linear Indications
2. Relevant rounded indications greater
than 5.0 mm ( 3/ 16 ins)
3. Four or more relevant rounded
indications in a line separated by 1.5
mm ( 1/ 16 ins) or less, edge to edge.
18.4 ASME Code B 31.1 Power Piping Para
136.4.3
18.4 ASME Code B 31.1 Power Piping Para
136.4.3
a) Hanya indikasi dengan dimensi terbesar
lebih dari 1.5 mm ( 1/ 16 in.) harus disebut
relevan,
b) Semua permukaan harus bebas dari :
1) indikasi memanjang yang relevant
2) Indikasi bundar yang relevan yang lebih
dari 5 mm ( 3/ 16 in.)
3) Empat atau lebih indikasi bundar yang
relevant pada satu garis yang terpisah
oleh 1/ 16” ( 1.5 mm) atau lebih kecil,
( jarak dari pinggir ke pinggirnya)
4) Sepuluh atau lebih indikasi bundar dalai
setiap 6 sq in ( 3870 mm2) dari
permukaan dengan dimensi utama
daerah ini tidak melebihi 6 inci ( 150
mm) dengan area yang diambil dilokasi
yang paling tidak menguntungkan
dibandingkan dengan indikasi yang
sedang dievaluasi
a) Only indications with major dimensions
greater than 1.5 mm ( 1/ 16 in.) shall be
considered relevant,
b) All surfaces to be examined shall be free
of:
1) Relevant linear Indications
2) Relevant rounded indications greater
than 5 mm ( 3/ 16 in.)
3) Four or more rounded indications in a
line separated by 1.5 mm ( 1/ 16 in.) or
less, ( edge to edge)
4) Ten or more rounded indications in any
6 sq in. ( 3870 mm2) of surface with the
major dimension of this area not to
exceed 6 in. ( 150 mm) with the area
taken in the most unfavorable location
relative to the indications being
evaluated
KS
PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 11 of 13
19 Perbaikan 19 Repair
Indikasi yang tidak diterima harus
dihilangkan dan diuji kembali, untuk
meyakinkan cacat telah hilang semuanya atau
ukuran cacat bisa diterima sebelum dilakukan
pengelasan kembali. Hasil perbaikan harus
diuji kembali dengan metode yang sama
dengan metode awal.
Unacceptable indications shall be
removed and re-examined to assure
complete removal of defects or to
acceptable size before re-welding.
Completed repair shall be re-examined by
the method originally used.
20 Demagnetisasi 20 Demagnetization
Jika sisa magnet di benda uji dapat
mengganggu pada proses berikutnya atau
penggunaannya, maka benda uji harus
didemagnetisasi sewaktu waktu setelah
selesai pengujian. Demagnetisasi bisa
menggunakan mesin MT yang bisa
menghasilkan magnetic flux yang cukup
dengan cara menggulung kabel di benda uji
dan secara bertahap amper diturunkan pada
step berikutnya atau benda uji dipanaskan
dengan menggunakan metode yang sesuai.
When residual magnetism in part could
interfere with subsequent processing or
usage, the part shall be demagnetized any
time after completion of the examination.
The demagnetization may use the MT
machine which produce sufficient magnetic
flux by wrapping the part with cable and
gradually decrease the amperes at the
following step or by heat treated the part
using applicable method.
21 Pembersihan Akhir 21 Post Cleaning
Pembersihan akhir harus dilaksanakan jika
material test magnetic particle yang
diaplikasikan pada benda uji dapat
mengganggu proses berikutnya dan dengan
menggunakan alat yang cocok.
The post cleaning shall be performed only
when magnetic particle test materials
applied on the part could interfere with
subsequent processing and using the suitable
means.
Exhibit 1 :
MAGNETIC PARTICLE TEST REPORT
KS
PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 12 of 13
Customer : Drawing No. : Rev. Report No : … … ..- MT… ..
Project
Name
: Procedure No. : Rev.
Unit No : Applicable CODE : NCR Ref No :
Material
Spec
: Welding Process :
MT Equipment : Yoke Other
Current Type : AC Other Serial No. :
Light Intensity : Light Source :
Particle : Visible Wet
Temperature : Particle application Spray Other
Brand’ s Name/ Types : Particle : White Contrast : Cleaner :
Batch no. of Particle : White Contrast : Cleaner :
Examination Method : Continuous Magnetizing
technique :
Minimum twice in each area, right angle each
other
Surface Prep. / cleaning : As welded As machined As ground Solvent Wipe
Time of Examination : After Welding After Hydro-test After PWHT Others
Scope of Examination : Base Metal Edge Prep Back Chipping
: Weld Part Repair Weld Others
Part Name Weld No. Thickness
( mm )
Result
Types of
Discontinuities
Accepted Rejected Remarks
Sketch ( Identify discontinuities listed above ) if necessary :
Examined by :
Customer Authorized Inspector
NDE Level :
Date : Date : Date :
KS
PT. KEHAN SUPPLY
Serving industry, mining and oilfield
Procedure No : 02 – QCP - KS
Revision : 00
MAGNETIC PARTICLE EXAMINATION
PROCEDURE
Date : January 26, 2012
Page No. : 13 of 13
Table T - 721
Requirements of a Magnetic Particle Examination Procedure
Requirement Essential
Variable
Non
essential
Variable
Par.
references
Magnetizing technique X 13
Magnetizing current type or amperage outside range specified by
this article or as previous qualified
X NA
Surface preparation X 10.1
Magnetic particles ( fluorescent / visible, color, particle size, wet /
dry)
X 8.1 / 8.4 /
8.5
Method of particle application X 14.1 / 14.2
Method of excess particle removal X 14.1
Minimum light intensity X 12.1
Coating thickness greater that qualified X NA
Performance demonstration, when required X 2.3
Examination part surface temperature outside of the temperature
range recommended by the manufacturer of the particles or as
previous qualified
X 2.1
Shape or size of the examination object X 1
Equipment of the same type X 7
Temperature ( within those specified by manufacturer or as previous
qualified)
X 2.1
Demagnetizing technique X 20
Post-examination cleaning technique X 21
Personnel qualification requirements X 6
Please Contact :
saleskehan@ gmail.com
0818.07489548
fax 62 21 5602582
Tampilkan Lebih Banyak
